Hontim Flame Machine

SF-200 Two-nozzle fire machine

Model: SF-200

220V
Voltage
180W
Power
7kg
Weight
dmx512
DMX Control

Product Description

Two‑nozzle fire machine — Dual‑Outlet Compact Flamethrower, No‑Preheat Quick‑Response Flame Effect

Engineered for small‑and‑medium concerts, nightclub performances, event ceremonies and indoor stage shows, this two‑nozzle fire machine delivers dual‑stream flame effects. Without preheating waiting time, it supports DMX512 and manual control, ideal for compact stage effect applications.

Key Features

Operating Voltage – AC220‑240V/60HZ.
180W Rated Power – Low‑power stable operation.
No‑Preheat Structure – No preheating required for instant‑trigger flame output.
Fuel Consumption – 8‑10 shots per 500ML bottle; single flame duration 1‑3 seconds.
Flame Spray Height – Above 1‑3 meters.
Maximum Working Pressure – 6 bar.
Dual‑Control Mode – Supports DMX512 signal control and manual operation.
Channel Setting – 3CH DMX channel configuration.
Simple Operation Interface – DIP switch and start switch for easy field debugging.
Packaging Form – Carton package.
Dedicated Consumables – 500ML per bottle flamethrower oil.

Technical Parameters

Preheating Time
No preheating required
Fuel Consumption
8-10 times/500ML/bottle (lasts 1-3 seconds)
Spray Height
>1-3 meters
Maximum Pressure
6 bar
Channels
3CH
Operating Interface
DIP switch/Start switch
Packaging
Carton
Consumables
500ML/bottle Flamethrower Oil

Quick Specifications

Brand Hontim
Model SF-200
Dimensions 600*150*490mm
Voltage 220V
Power 180W

Compatible Consumables
