Hontim Spark Machine

PF-800 Headmoving Spark Machine(Dual-head)

Model: PF-800

220V
Voltage
1300W
Power
23.5kg
Weight
dmx512
DMX Control

Product Description

Headmoving Spark Machine(Dual‑head) — Dynamic Rotational Spark Effects, Flexible Multi‑Way Control

Engineered for concerts, wedding events, club venues and various live stage performances, this dual‑head moving spark machine delivers dynamic rotating spark output. Featuring dual‑hole stepless rotation, electromagnetic heating and multi‑control options, it creates rich and variable visual spark effects for diverse stage scenarios.

Key Features

Powerful 1300W Total Power – Delivers stable spark output for vivid dynamic stage visual presentation.
Dual‑Hole Stepless Rotation – Dual‑head design with stepless rotating spraying direction for flexible multi‑angle spark projection.
Adjustable Spraying Height – Spraying height ranges from 1‑5 meters; 5‑level adjustment via control panel, 3‑level adjustment via remote control.
22mm Spraying Inner Diameter – Optimized nozzle inner diameter ensures smooth and consistent spark ejection.
Efficient Electromagnetic Heating – Completes heating within 3‑5 minutes for fast pre‑show preparation.
Dual Control Options – Supports DMX512 and wireless remote control for flexible on‑site operation.
Durable Aluminum Housing – Aluminum shell available in black anodized or white painted finish.
Triple Independent AC Motors – Equipped with 3 independent large AC motors with automatic material clearing function to prevent blockages.
260g Material Box Capacity – 260g capacity material box for dedicated spark consumables.
Complete Standard Accessories – Supplied with 3‑meter 1.5 sq mm power cord, 3‑meter signal cable, 2.4G multi‑functional remote control and hex wrench for material clamping.

Technical Parameters

Spraying Direction
Dual-hole stepless rotation
Spraying Height
1-5 meters (5 levels on the control panel, 3 levels on the remote control)
Spraying Inner Diameter
22mm
Heating Method
Electromagnetic heating (3-5 minutes)
Shell Material
Aluminum (black anodized/white painted)
Motor Configuration
3 motors (independent large AC motors, with automatic material clearing)
Material Box Capacity
260g
Accessories
3-meter 1.5 sq mm power cord, 3-meter signal cable, 2.4G multi-functional remote control, hex wrench for material clamping

Quick Specifications

Brand Hontim
Model PF-800
Dimensions 505*420*460mm
Voltage 220V
Power 1300W

Compatible Consumables
